RY20N20A2

發布者：日月辰科技

	規格型號	RY20N20A2

	產品參數	電壓：200V，電流：20A，Vgs：30V，Rds：0.17Ω

	產品品牌	日月辰	產品封裝	TO-252

	?
詳細說明

RY20N20A2 TO-252封裝

Description

This N-Channel MOSFET uses advanced trench technology and design to provide excellent RDS(on) with low gate charge. It can be used in a wide variety of applications.

Features

1) VDS=200V,ID=20A,RDS(ON) =180MΩ (Max)@VGS=10V

2) Low gate charge.

3) Green device available.

4) Advanced high cell denity trench technology for ultra RDS(ON).

5) Excellent package for good heat dissipation.
